Migrating From gp2 to gp3 Volumes to Lower AWS EBS Costs

Save up to 20% on AWS EBS costs by switching from gp2 to gp3 volumes. This guide shows you how to easily make the change and optimize your expenses.

Patrick Londa
Author
Oct 7, 2022
 •
4
 min read
Share this post

In December 2020, Amazon Web Services (AWS) announced the availability of gp3, the latest version of general purpose SSD volumes for Amazon Elastic Block Store (EBS).

Prior to this, there had been only a linear relationship between EBS volume performance and storage capacity, which led to over-provisioning ⁠and non-cost-effective pricing. Now, with gp3, if you require higher IOPs (input/output operations per second) and throughput, you don’t need to also pay for excess storage.

When you switch from gp2 volumes to gp3 volumes, you lower your costs by 20%. For example, in the us-east-1 region, gp2 volumes cost $0.10/GiB-month compared to gp3 volumes at $0.08/GiB-month.

With gp3 volumes, you get a baseline performance of 3,000 IOPs and 125MB/s at any volume size, with the ability to scale up to 16,000 input/output operations per second (IOPS) and 1,000 MiB/s for additional fees. With high performance and lower costs, making this switch is easy to justify.

In this guide, we’ll show you how you can switch your gp2 volumes to gp3 to lower your costs by 20%.

Blink Automation: Find and Upgrade AWS EBS Gp2 Volumes
AWS + Slack
Try This Automation

How to Switch from GP2 Volumes to GP3 Volumes

You can make the switch from GP2 volumes to GP3 volumes by either using the console or the AWS CLI, and you won’t disrupt your running EC2 instance.

Using the AWS console

1. Open EC2 console.

2. Choose Volumes.

3. Select which gp2 volume you need to modify.

4. Choose Actions ---- Modify Volume.

5. Once your chosen volume's ID and current configuration are shown in Modify Volume window, set your desired configuration values as follows:

    a. Modify type by choosing gp3 for Volume Type.

    b. Modify size by entering a new value for Size.

    c. Modify IOPS by entering a new value for IOPS.

    d. Modify throughput by entering a new value for Throughput.

    e. Having completed changes to volume settings, choose Modify.

    f. Choose Yes, when prompted for confirmation.

You can repeat these steps for as many gp2 volumes as you have to scale this cost savings.

Using the AWS CLI

Use the modify-volume command so you migrate to gp3. This is an example of an 8-GiB gp2 to gp3 migration command:

aws ec2 modify-volume --volume-type gp3 -volume-id vol-11111111111111111

The output should look like this:

{
  "VolumeModification": {
    "VolumeId": "vol-11111111111111111",
    "ModificationState": "modifying",
    "TargetSize": 8,
    "TargetIops": 3000,
    "TargetVolumeType": "gp3",
    "OriginalSize": 8,
    "OriginalIops": 100,
    "OriginalVolumeType": "gp2",
    "Progress": 0,
    "StartTime": "2021-02-03T13:38:08+00:00"
  }
}

 By running this command and making this change, you have now reduced your monthly AWS costs for this volume. You will need to repeat this process for each gp2 volume.

Automating Your Migration to GP3 Volumes

Switching your gp2 volumes over to gp3 volumes is a simple way to lower your costs, but the process requires manual action on each volume. If you have dozens or hundreds of gp2 volumes, this can be highly time-consuming. And then what happens if an even more cost-effective gp4 volume is announced?

For migrations like this, automation can save you significant time and make these optimizations more feasible at scale.

With Blink, you can run this automation to identify and alert you to any gp2 volumes associated with your EC2 instances. You can then click a button in Slack and migrate that volume to gp3 instead.

Blink Automation: Find and Upgrade AWS EBS gp2 Volumes
Blink Automation: Find and Upgrade AWS EBS gp2 Volumes

When this automation runs, it executes the following actions:

  1. Detects gp2 volumes that are not tagged to ignore.
  2. Asks via Slack whether to upgrade, tag to ignore, or do nothing.
  3. If approved, upgrades each gp2 volume to a gp3 volume.

You can import this automation from the Blink library and customize it however you like.

In Blink, you can also create automations from scratch to meet your team’s unique needs using the hundreds of drag-and-drop actions available from a wide range of tools.

Get started with Blink today and see how easy automation can be.
